garsault to the rescue

As expected both the text and the illustrations are much easier to understand in Garsault than Diderot.

The Lingerie Stitches from Garsault, I think I need to use c. I was wondering if there were more variations on this- such as running the needle through the fold to hide stitches almost entirely but it looks like a slanted stitch as per the text.

A, Le Surjet.
B, Le Point noué ou de boutonniere.
C, Le Point de côté.
D, Le Point devant.
E, Le Point de chaînette.
F, L’arriere-Point.
GMH, Trois Figures pour la Couture rabattue.

A, The Overlock.
B, Knotted or buttonhole stitch.
C, The Side Point.
D, The Point in front.
E, The chain stitch.
F, The backstop.
GMH, Three Figures for Folded Stitching.

The Lingerie Stitches of Diderot

The Tailors stitches for hemming:

Garsault

Of note is the upper of Fig 6; the thread is clearly seen passing through the underside to the top, then the thread not returning through the upper but between upper and lower then through the lower and back up.

Also of note is that k, or the same figure also shows this clearly as the under layer is set slightly under.

And this helps with the text:

6.
Le point à rabattre sous la main.
Il se fait comme le précédent, excepté qu’ayant percé l’étoffe supérieure,vous allez par dehors piquer l’étoffe inférieure au travers; puis vous les percez toutes deux en remontant: on se sert de ce point pour coudre la doublure au-dessus quand il la dépasse : k dessus, n dessous.

6.
The point to fold at hand.
It is like the preceding, except that having pierced the upper stuff, you go outside to stitch the bottom stuff through; then you pierce them both up: we use this point to sew the lining above when it exceeds: k, above, n below.

This is not as clear in the Diderot plate of the same stitches, the stitches do not seem to weave in Fig 16, and in Fig 17 there is no indication of the underlayer.

Diderot.

So that has made it much easier for me to not use this set of stitches for my mantua hemming as it is not formed this way.

I think a simple slanted stitch like I normally use will be fine for the seam allowances along the joins of the mantua petticoat and seen in the Lingerie sections will be enough.

mystery boning- physics and chemistry

Several years ago I managed to find several lengths of lovely rigid plastic boning. I have not found anything like it ever again. I do have some of the now readily available boning variously known as German Plastic Boning and Synthetic Whalebone (which may or may not refer to the same thing) but they just are very different for purpose.

I have a BSc in Biochemistry so plastics/resins hold a real fascination. I mean obviously I had to learn a fair bit about the resins used in fibreglassing because it changes how you use it. For example when to laminate and when to work the entire thickness- basically each batch you mix and cure becomes one giant molecule, each separate batch then only bonds to the surface- it’s more complicated but basically this is also why I like to use fillers and thinners with the same product- that surface bond is still not to be sneezed at. I am so allergic. To epoxy. Polyester is just nasty. But the pros of epoxy as basically safety; flex and resistance to flame.

So. I have a sample and I can do a few very simple tests to find out what the primary plastic is. But plastics are not pure, they may be made from several sources and may have additives and these will affect physical properties.

I don’t think I have enough for professional testing but I should be able to follow this, with a bit of help:

https://www.modernplastics.com/wp-content/uploads/2015/03/how-to-identify-plastics.pdf

Of interest is this: melamines smell like fish and formaldehyde! I definitely have a few samples of this.

The cut edge is very similar to the cut edge of the Wissner product as stocked by all the main sellers. It goes opaque with compression in the centre of the cross section. It is not a pure clean cut either, the edge is somewhat flaked. It doesn’t crumble. So already that is a test.

I can easily test density-ish. If it floats in water (“room temperature”) or sinks.

So I will see how it burns- speed to catch, smoke, smell, flame, drip…

I can’t quite tell if there is pigment. It is cooler in tone than the other boning but it’s quite subtle. And it could be a matter of different pigments vs presence or absence of pigments. Zinc oxide vs Titanium etc. etc. There might be a bluing pigment?

I have been trying to find the boning online and the easiest way to identify it is the cross section. It is much more oval than what is readily available. And that cross section adds to the rigidity.

In part this: https://en.wikipedia.org/wiki/Torsion_constant because it is harder to twist. But mostly because of
https://en.wikipedia.org/wiki/List_of_second_moments_of_area

So sewing huh. Physics and chemistry do matter. It is not just an issue for support materials like this! Fabric is an exquisite interplay. The fibre content, the processing, the spinning, the weaving, the dyeing, the sizing.. it all affects whether you can even wash a fabric without losing properties. And that then affects what you can do to dye or stitch or store the fabric.

Cutting fabric is a calculated risk in very many ways. You cannot restore a fabric to precut. It’s not just a matter of aesthetics. It will affect the kind of stitching and fibre content and thickness and twist of thread used to sew it back together. Hand vs machine is not even a given. The fabulous cloth of gold fabric from Sartor Textiles was a dream to machine sew with tiny stitches and the smoothest polyester thread I can use with a microtex needle. Slightly harder to hand sew and it really really needs to be pressed with heat.

Anyway.

Time for a break.

easy mantua cutting

I did manage to cut my fabric panels for my mantua, it really is pretty darm easy as it is all on the grain rectangles. It is pretty much exactly what I expect from a pre-1920s measure, cut, fit process. It looks a bit different but ultimately it’s a case of wait to floor, shoulders to waist and that’s it. Everything else is adjustable to suit.

I knew I wanted my side extensions to be only one full width of fabric (so two widths of a more in era width. I cut (tore) one width from waist to floor plus a hand width for turnings. Then folded on the diagonal to form the two side extensions.

The underskirt is cut from three drops of fabric as these tend to be between 5-7 widths of in era fabric widths. I will wind up with side openings which will allow me to wear pockets underneath. The Henri Bonnart illustrations show a lot of openings for pockets.

The front of the robe was cut from one full width of fabric as long as from my shoulder to floor plus two hand widths. One hand width is to extend the fronts over the shoulder, the other is for turning.

To cut the back panel I laid the extensions next to the front panels and lined up the remaining fabric from top of the front panel down to waist and then followed the diagonal of the side extensions.

I didn’t want a very long train so I cut a curve about 3-4 hand widths.

The rest of the fabric will be used for sleeves and facings.

Since these I have machine stitched the joins and pressed them back ready for stitching. I haven’t yet done so as I need to really look through the Diderot stitches. Okay. Not totally clear but:

https://quod.lib.umich.edu/d/did/did2222.0000.178?view=text;rgn=main
The Encyclopedia of Diderot & d’Alembert Collaborative Translation Project.
PLANCHE IX.
Tailleur d’habits et tailleur de corps

Livre L’Encyclopédie. [38], Arts de l’habillement : [recueil de planches sur les … Diderot, Denis (1713-1784)
https://gallica.bnf.fr/ark:/12148/bpt6k9978d/f46.item

Points de couture.

Fig, 1. 2. & 3. Elévation & places de dessus & de dessous du point de devanten piquant les deux étoffes de haut-en-bas & de bas-en-haut.
Fig, 4. 5. & 6. Point de côté ramenant le fil en-deffous par-dehors après avoir piqué les deux étoffes.
Fig, 7. 8. & 9. Point-arriere ou arriere-point, repiquant de haut-en-bas au milieu du point-arriere après avoir piqué de bas-en-haut.
Fig, 10. 11. & 11. Point lacé comme le point-arriere, lieu qu’il fe fait au- en deux tems, revenu en-hauton ferre le point, & retournant l’aiguille on repique en-arriere commeau précédent.
Fig, 13. 14. & 15. Point à rabattre fur la main piquant le haut-en-bas & de bas-en-hauten-avant les points drus espacés & également.
Fig, 16. 17. & 18. Point à rabattre fous la main commele dernier au-lieu qu’ayant percé l’étoffe supérieure on pique-l’étoffe inférieure par-dehors, ensuite on pique les deux en remontant.
Fig, 19. 20. & 21. Point à rentraire comme le point à rabattre fur la main se faisant en deux tems en retournant l’aiguille avant tout il faut joindre à point fimple les deux envers l’étoffe retournée on ferre de ce point les deux retours il faut pour cela très-peu d’étoffe &les points très-courts.
Le point perdu n’eft qu’un point-arriere ajouté au precédent.
Fig, 22. 23.& Point traversé, couture à deux fils croisés.
Fig, 25. A, premiere opération; point coulé ou la passe, c’eft la boutonniere tracée de deux fils. B, la passe fermée du point de boutonniere. C, la passe achevée & terminée de deux brides à chaque bout quel’on enferme de deux rangs de points noués

Google translated:

BOARD IX.
Sewing stitches.
Fig, 1. 2. & 3. Elevation & places from above & from the fronten point pricking the two fabrics from top-to-bottom & bottom-to-top.
Fig, 4. 5. & 6. Side point bringing the wire in-bursts from outside after stitching the two fabrics.
Fig, 7. 8. & 9. Point-back or back-point, pushing up and down in the middle of the back-stitch after dipping from below upwards.
Fig, 10. 11. & 11. Point laced like the point-back, place which it is made in two tenses, returned to the top, turns the point, and turning the needle backwards.
Fig, 13. 14. & 15. Point to be folded on the hand, stitching up-down and down-up in front of the thick points spaced & equally.
Fig, 16. 17. & 18. Point to be folded in the hand as the last one instead of having pierced the upper stuff, the lower stuff is thrown out, then the two are stitched upwards.

Fig, 19. 20. & 21. Point to point as the point to be folded on the hand being done in two times by turning the needle before all must be joined at the same time the two to the returned fabric we iron this point both returns require very little material and very short points.
The lost point is only a back-point added to the previous one.
Fig. 22. 23. & Crossed point, cross-stitched seam.
Fig, 25. A, first operation; cast point or the pass, it is the buttonhole traced two sons. B, the closed pass of the boutonniere point. C, the pass is completed & completed with two straps at each end which enclose two rows of knotted stitches

Google translate can’t really understand it. But I am no better off reading heh translation here: https://quod.lib.umich.edu/d/did/did2222.0000.178?view=text;rgn=main

Figures 13. 14. and 15. Overhand hem stitch piercing from top-to-bottom and from bottom-to-top in front, the stitches densely spaced and even.
Figures 16. 17. and 18. Underhand hem stitch [is] like the last, except that having pierced the upper fabric one pierces the lower fabric at the outside, one pierces the two together fortifying.

The Encyclopedia of Diderot & d’Alembert Collaborative Translation Project.

http://hdl.handle.net/2027/spo.did2222.0000.178


https://quod.lib.umich.edu/d/did/did2222.0000.178?view=text;rgn=main
The Encyclopedia of Diderot & d’Alembert Collaborative Translation Project.
PLANCHE X.

Livre L’Encyclopédie. [38], Arts de l’habillement : [recueil de planches sur les … Diderot, Denis (1713-1784)
https://gallica.bnf.fr/ark:/12148/bpt6k9978d/f46.item

Fig, 1. 2. & 3. Points noués simples de neuf différentes formes.
Fig, 4. Points noués doubles de trois différentes sortes.
Fig, 6. & 7. Points croisés de simples & doubles de neuf différentes sortes.

Google translation:

Fig, 1. 2. & 3. Simple knotted stitches of nine different shapes.
Fig, 4. Double knotted stitches of three different kinds.
Fig, 5. 6. & 7. Cross points of single & double of nine different
kinds.

To be honest it is the section on linen items that has nice clear hemming illustrated.

LivreL’Encyclopédie. [38], Arts de l’habillement : [recueil de planches sur les … Diderot, Denis (1713-1784)
https://gallica.bnf.fr/ark:/12148/bpt6k9978d/f46.item
PLANCHE Iere.

Livre L’Encyclopédie. [38], Arts de l’habillement : [recueil de planches sur les … Diderot, Denis (1713-1784)
https://gallica.bnf.fr/ark:/12148/bpt6k9978d/f46.item

FIGURES
Fig, 1. Le point de surjet.
Fig, 2. Le point de côté.
Fig, 3. Le point-arriere ou arriere-point:
Fig, 4. Le point devant.
Fig, 5. La couture rabattue.
Fig, 6. Le point noué ou point de boutonniere.
Fig, 7. Le point de chaînette.
Fig, S. Le point croisê.
Fig, 9. Peignoir en pagode:
Fig, 10. Bonnet piqué.
Fig, 11. Coëffure de dentelle.
Fig, 12. Coëffure à deux rangs ou à bavolet.
Fig, 13. Grande coëffe en mousèline. A coëffure en papillon sur une tête de carton.

Google translation:

FIGURES
Fig, 1. The overlock stitch.
Fig, 2. The side point.
Fig, 3. The rear-end or back-point:
Fig, 4. The point in front.
Fig, 5. The seam folded.
Fig, 6. The lockstitch or boutonniere.
Fig, 7. The chain stitch.
Fig, S. The point crossed.
Fig, 9. Bathrobe in pagoda:
Fig, 10. Quilted hat.
Fig, 11. Scallop Coif of lace.
Fig, 12. Coeffure Coif with two rows or bolster.
Fig, 13. Large mussel cockerel mouseline coif. A butterfly coif on a cardboard head.

Working on the mantua

I finally put pencil and ink to paper and got my idea in colour.

Why? The direction of boning is as important as the shape of the pieces. If the boning is vertical it tends to follow the shape of the body more closely- it scoops in at the waist and out over ribs and bust and padding. On the diagonal it acts to channel soft body tissue into the seam with the V. So this gives us the variation in the conical shape.

I think I have found the perfect set of stays to mimic for my own. I am not sure about the breadth across the upper front for me but otherwise it is close.

https://www.metmuseum.org/art/collection/search/90404

Date: late 17th–early 18th century
Culture: French
Medium: silk, metallic thread
Credit Line: Purchase, Irene Lewisohn Bequest, 1975
Accession Number: 1975.34.2a–c

early 1700s – Auction House Coutau- Bégarie – Corps à baleines, début du XVIIIe siècle,en damas ramagé rose, piqûres rectilignes soulignant les baleines. Devant en pointe arrondie à effet de corset lacé matérialisé par des dentelles aux fuseaux en sorbec argent, basques gainées de peau. Laçage à oeillets dans le dos, (quelques usures).

I am mostly happy with my stays but I’ll unpick the front panels as I want them on the straight. A whole lot of stays in museums are just labeled “18thC” which is not really helpful given how much the engineering of these stays changed.

I used my Effigy stays for fit and redrew seam lines. I used the Garsault diagram not the Diderot pattern. Garsault is slightly easier to see all the seam lines.

Compare Art du tailleur : contenant le tailleur d’habits … Garsault, François-Alexandre-Pierre de (1693-1778):

with “Tailleur d’habits et tailleur de corps,” Encyclopédie ou Dictionnaire raisonné des sciences, des arts et des métiers, vol. 9 (plates). Paris, 1771.

:

I also had Leloir in mind to look for consistencies and differences.

I also used the two sets of stays from Corsets and Crinolines to again look for consistencies and differences.

And also used Hunnisett as a guide, there is a pattern scanned out there labeled as from Waugh which is actually from Hunnisett.

This 1680s set has vertical boning strategically placed at CF CB and sides. This keeps the shape very straight and in fact with a little scoop and tilt back of the front. This follows fashion.

This from the 1730s has a lot of boning on angles to allow for the front to tilt forward every so much. There is still a sweep to the waist it is the start of the very lilted forward shape we see once busks really start to take hold.

Interestingly a very similar bit of engineering goes on for the S front corsets of the 1900s. A very rigid straight busk cases the hips to tilt back and the upper tilt forward, it’s not just the rigid straight busk that is similar but also the use of very diagonal, almost horizontal seams.

I need a nearly vertical front that curves at almost the same degree from top to bottom.

Maria Luisa of Savoy (1688-1714)

This portrait neatly shows the push up effect of the stays (narrow and tall with lots of vertical bones) but the start of a bit of a tilt forward due to the start of a very straight and rigid font.

I’ve cut them so that I can use the front of each panel for vertical support while the back is tapered more or less.

I love stays with a laced open front as it can allow for a pair of stays to be adjusted a bit to mimic some later styles- eras where length becomes defining. In fact there are a few sets of stays dated to the 1780s that use so many of these features- long skinny tabs that mostly have the boning going straight through, lots of vertical boning.

I do though need some new boning. It’s difficult because no two manufacturers use the same process. My favourite was very clearly extruded and so there are parallel lines running through it. It was very rigid, and was quite oval in cross section. This is important for structure as it’s harder to bend that shape than a more flat cross section.

But I do have steels to help support, once I can cut them. So many projects on hold as I need the support structure to start patterning. I can’t use the aviation shears that came with them. So I’m trying to get creative.

tired

It’s been a week of extreme introspection, weariness, and wariness, so before I post about costumes I’d like to use whatever platform I have to connect.

For anyone in Aotearoa the 1737 support line is there. It is there for everyone. Any time. It is free (you may get a message from your carrier that a text could not be sent- they say it will be.)

If you would like to help there are a few official charitable accounts, please, please listen to local voices on this.

https://www.facebook.com/VictimSupportNZ/posts/2957163374294656

https://givealittle.co.nz/cause/christchurch-shooting-victims-fund (this is also the page our national support agencies are directing people to.)

For those still trying to contact families:

https://familylinks.icrc.org/new-zealand/en/Pages/Home.aspx

There is a direct link from there for those who need to travel here- visa information etc.

I am okay, emotionally I’m not, but right now and for some time if anyone would like to reach out, please reach out to the above first. The website has and is always intended as a conduit to teach or help others. This is no different.

new site

I have felt overwhelmed by my blog here for a while so I have been going through older entries looking for my “sharing” posts vs my progress posts and trying to categorise them all.

I think I now have a handle on what I want but it really is requiring a lot of prep. I need to create new categories and tags, I need to remove excess tags and bring those posts over to new tags.

I think I have a really good start to the system and a way to create media folders that match those categories. And thus also a way to get media content in the same date folder of any recovered posts from my older site.

mantua easy draft

I spent the day digitising a cheat draft for a mantua. It’s very similar to Hunnisett but what I have tried to do was show the rationale behind it. This pattern is for a

(Pattern on fabric on the fold.)


It uses minimal measurements just like the originals. From left to right are the discreet drops of fabric that can be torn before any cutting or pleating is started.

My previous overlays of extant mantua show a fabric width of between 50 and 65cm in silk and over 100cm in wool. So I have tried to show the pattern shapes on 150cm/60″ wide fabric. But I also tried to indicate 50cm divisions.


The front length is taken from behind the shoulder to waist to hem (over hips) plus turnings. Here the front is 185cm to include a generous turning (10xm.)

The side widths are extensions cut from the full width, here I have limited to the width of the fabric but these could be cut wider by butting more fabric to the far side and continuing the same diagonal line. Turning is automatically included this way.

The back length is taken from the shoulder to waist plus the length of the diagonal line of the side extensions, and then extra to taste for the curve of the train.

The underskirt is then two full width drops of fabric or 6 drops of 50cm wide fabric from waist to hem (over hips) plus a generous turning (10cm.) Original skirts are between 5-7 drops, records describe openings being at the side or Centre Back. If a CB opening is desired then the joins should be turned to the sides and the CB fold slashed about 2 hand widths deep. The front will then also be on the fold.

The sleeves can be cut from a single drop of fabric approximately the same length as is used by the body. These vary greatly by decade but this allows for pleats and length to elbow.

Facings and cuffs can be cut from the greyed out left over fabric or from a dedicated drop of your choice.

To alter for width the side seam on the front and back panels can be moved further out so that the diagonal line is entirely on the extensions.

This is based on my proportions and is very much a “guesstimate” as I tend to err on the side of extra length.

Construction starts with joining the underskirt turning up the hem then pinning to the form which has been dressed with a petticoat.. This ensures the hem is entirely across the grain and thus the waist will form a gentle wave.

The waist can be turned and overhanded to a waist tape (or two for side openings) the waist should be pleated or gathered, with the direction of pleats pointing to the back. This skirt should be lined or at least have a deep facing to allow the hem to hang neatly and with body.

The mantua will need a shaped lining that should be taken on the body or a stand correctly shaped with stays of the right shape.

This is then pinned to the form and the main fabric pleated over that.

The back of the mantua is the foundation for fit so start at waist and pin up for the centre back and then fold the side backs as desired. The fabric can be slashed at the side to avoid wrinkles at the waist. The side seam should sit slightly to the back rather than strictly at the side.

The fronts of the mantua can be joined to the extensions (seam allowance to the outside for a later style, to the underside for earlier) and the full hem turned. This again allows for the hem to be entirely across the grain and the fronts can then be pinned and pleated on the form again aligning the hem to the correct level by taking up or letting down at the waist. Then pin the front pleats and slash the side waist to fit.

The front side should be folded in and the edge tacked to the back, the join between the extensions and back should be sewn so as to be on the inside once draped.

sooo.. Freya is back on the cards

I recently shared some of my art on instagram (@thefrockchick) of my own variations on The Snow Queen so it’s a fantastic coincidence that today I finally found some non-woven faux suede which is exactly what I need to recreate this gown which has also been on my must do list.

This gown was originally made from leather. It was dyed black and the skin side silver leafed and the reverse painted with a mica pigment that is a rich blue.

I can’t really afford that amount of leather not the weight (it’s about 35kg-40kg from what I remember) and the material I have is already over 10kg.

I worked out the pattern of the scales over a year ago but didn’t really attempt to work out actual amounts of “leather” needed. I should have enough if I am really careful and possibly not have quite an epic train. It might be a matter of a half meter short.

I do know how to treat the material to get the silver and blue sides (I’ll use “Misty Blue” Pearlx pigments, and probably resolene to bond it to the material) I just really need to get my template perfect to be able to make a scale pattern.

For the silver side I will probably also use pigments but maybe in a urethane paint system- I have gold and I think the silver will work especially if I also powder the urethane down so that there are particles that are embedded and some that are tacked down on one side.

But I love this costume because it uses both the familiar and unfamiliar. Woven leather and shot organza, a very loose gauze, and faceted beads.

It’s also basically shaped strips which is a challenge for patterning as you need to make sure the grain is aligned to the centre of each panel. So I might do a paper template, divide that and then snip and tape into new shapes.

I have to make some changes to my day to day activities if I want to make this at all, let alone soonish. So I’ll have to set myself some boundaries and stick with them.

manteau-or not (inc patterns)

We tend to think of all open robes of the 1680s to early eighteenth century as “mantua” or “manteau.” However there are at least two documentable pattern types to over gowns of this era.

The mantua as often described is a garment with a very unique construction. It puts all the side skirt shaping on a single wedge of fabric, made of several widths of fabric, entirely in line with the front panels.

To create my own pattern I collected and redrew every pattern of an extant garment published and redrew them to the same scale (1/4) and overlaid them to understand the interplay between each pattern piece. I ignored facings, cuffs, and petticoats and focused on the over garments.

All current “mantua” patterns overlaid to show the proportions of each.

Most garments with a straight front and back seam allow for narrower extensions on the front and back of the skirts, and this is true from the sixteenth century to modern times. The four gore skirt is built on this basic shape.

This distinction does seem to be borne out by Holme who wrote of garments made by a tailor and does differentiate between a gown and a mantua, later explaining that they are equally diverse:

“Of the Taylor, with the parts of the Doublet, Coat, Breeches, Cloak, Womens Gowns, Mantues, Wastcoats, and Petticoats… Of the Semster, Laundress, Needle-work Mistress, with the severall terms of Needle-work.

The academy of armory, or, A storehouse of armory and blazon containing the several variety of created beings, and how born in coats of arms, both foreign and domestick : with the instruments used in all trades and sciences, together with their their terms of art : also the etymologies, definitions, and historical observations on the same, explicated and explained according to our modern language : very usefel [sic] for all gentlemen, scholars, divines, and all such as desire any knowledge in arts and sciencesHolme, Randle, 1627-1699. https://quod.lib.umich.edu/e/eebo/A44230.0001.001/1:7.3.3?rgn=div3;view=fulltext

This more traditional and sustained pattern type of dividing the side fullness between the front and back can be seen in the patterns of Albayzeta from 1720. Included are several “ropa de levantar.”

edited from: Geometria y trazas pertenecientes al oficio de sastres donde se contiene el modo y orden de cortar todo genero de vestidos españoles, y algunos Estrangeros, sacandolos de qualquier ancharia de tela, por la Vara de Aragon y explicada esta con todas las de estos Reynos, y las medidas que usan en otras Provincias estrangeras
Front Cover
Juan Albayzeta
por Francisco Revilla, 1720 – 95 pages

https://books.google.co.nz/books?id=LOPc3rKe1-gC

This pattern appears to be for a garment with a very long train, though there seems to also be a secondary hemline drawn where the skirt back would just touch the ground- most of the patterns for “rope de levantar of this book are of the shorter type.

Of the extant garments that have been patterned the Danish gown most closely resembles this. This garment has not been digitised and is not currently on display.

Moden i 1700-årene
Author: Ellen Andersen
Publisher: [København] : Nationalmuseet, cop. 1977.
Series: Danske dragter

https://www.worldcat.org/title/moden-i-1700-arene/oclc/835178454?referer=di&ht=edition

It is possible to see the seam lines in the first photo that confirms the pattern draft that puts narrow wedges on both the side front and side back seams.

(ETA photos of details:)

My redrawing after a pattern in Moden i 1700-årene by Ellen Andersen

Moden i 1700-årene
Author: Ellen Andersen
Publisher: [København] : Nationalmuseet, cop. 1977.
Series: Danske dragter

https://www.worldcat.org/title/moden-i-1700-arene/oclc/835178454?referer=di&ht=edition

This also seems to be the construction of a Norwegian garment that shares the same heavily pleated sleeve shape.

There is an open robe in Norway’s National Museum that seems to be of the same construction but is in fact a single wedge each side but it is in line with the back panel.

Datering: Ca. 1720
Betegnelse: Drakt
Inventarnr.: OK-dep-01160
Eier og samling: Nasjonalmuseet, Designsamlingene
Foto: Nasjonalmuseet / Larsen, Frode Last ned.

http://samling.nasjonalmuseet.no/no/object/OK-dep-01160

It seems to be fairly unique to this garment to align the single wedges to the back. Could this be a mistake- many dresses of the nineteenth century have the gores reversed at the sides- or deliberate. The skirt is narrow and is worn with a very solid and full underskirt. This arrangement could mean the best display of the brocade pattern was at the side back.

(ETA: detail photos of the grainlines)

Of the mantua type we are left with several garments in both English and American museums.

The earliest example appears to be the Kimberley gown held at the Metropolitan Museum in New York. The earliest date appears to be 1695.

Mantua
Date:late 17th century
Culture:British
Medium:wool, metal thread
Credit Line:Rogers Fund, 1933
Accession Number:33.54a, b

https://www.metmuseum.org/art/collection/search/81718

This garment has been pattern by both Nora Waugh and Blanche Payne, they differ slightly but the principle is the same and in both patterns the side fullness is entirely in line with the front panel.

My redrawing after a pattern in The Cut of Women’s Clothes, 1600-1930 by Norah Waugh- note there is no join line in this draft.

The cut of women’s clothes, 1600-1930
Author: Norah Waugh; Margaret Woodward
Publisher: New York : Routledge : Theatre Arts Books, [1968] ©1968

https://www.worldcat.org/title/cut-of-womens-clothes-1600-1930/oclc/250274
My redrawing after a pattern in History of Costume by Blanche Payne-note this join line is in the original draft.

History of costume, from the ancient Egyptians to the twentieth century. Drawings by Elizabeth Curtis.
Author: Blanche Payne
Publisher: New York, Harper & Row [1965]

https://www.worldcat.org/title/history-of-costume-from-the-ancient-egyptians-to-the-twentieth-century-drawings-by-elizabeth-curtis/oclc/1086817570&referer=brief_results

The next garment that has been patterned is from Shrewsbury c1710.

Mantua.18th century (1710). Shrewsbury Museums Service (SHYMS: T/1973/6/1). Image sy14193

http://www.darwincountry.org/explore/022360.html?ImageID=22370&Page=42#Gallery

This was patterned by Janet Arnold (Patterns of Fashion 1: Englishwomen’s Dresses and Their Construction C. 1660-1860).

This garment also uses widths of fabric to create a single wedge extension each side and in line with the front panels.

My redrawing after a pattern in Patterns of Fashion 1 by Janet Arnold

Patterns of fashion. . 1. : Englishwomen’s dresses and their construction c.1660-1860.
Author: Janet Arnold
Publisher: London : Macmillan, 1977.

https://www.worldcat.org/title/patterns-of-fashion-1-englishwomens-dresses-and-their-construction-c1660-1860/oclc/248594714&referer=brief_results

(ETA: I have divided the pattern so that the shapes can be compared more easily to the other garments- this garment is made in continual lengths from front hem to back hem with the sleeves not cut out but rather shaped by pleating. The pattern can be easily put back as the dividing lines are the only diagonal lines in the draft.)

Of special interest is the length of the front of the mantua. It is quite short (see image of overlaid pattern drafts.). Holme confirms that this is a common feature of mantua.

“A mantua is a kind of loose Coat without stayes [sic] in it, the Body part and Sleeves are of many fashions as i have mentioned in the Gown Body; but the skirt is sometimes no longer than the Knees, others have them down to the Heels. The short skirt is open before, and behind to the middle.”

The academy of armory, or, A storehouse of armory and blazon containing the several variety of created beings, and how born in coats of arms, both foreign and domestick : with the instruments used in all trades and sciences, together with their their terms of art : also the etymologies, definitions, and historical observations on the same, explicated and explained according to our modern language : very usefel [sic] for all gentlemen, scholars, divines, and all such as desire any knowledge in arts and sciences Holme, Randle, 1627-1699. https://quod.lib.umich.edu/e/eebo/A44230.0001.001/1:7.3.3?rgn=div3;view=fulltext

This next garment from 1720-1730 and is housed at the Museum of London and patterned by Zillah Halls in Women’s Costumes 1600-1750: London Museum. This is made from chartreuse silk and is again of this single wedge each side construction. This garment is not currently digitised or on display.

Women’s costumes 1600-1750,
Author: Zillah Halls; London Museum.
Publisher: London, H.M.S.O., 1969.

https://www.worldcat.org/title/womens-costumes-1600-1750/oclc/49093
My redrawing after a pattern in Women’s Costume 1600-1750 by Zillah Halls

Women’s costumes 1600-1750,
Author: Zillah Halls; London Museum.
Publisher: London, H.M.S.O., 1969.

https://www.worldcat.org/title/womens-costumes-1600-1750/oclc/49093

This mantua is again shorter than a matching petticoat would be (see image

Another garment at the Museum of London was patterned by Nora Waugh, but not photographed. It is from 1735-1745 and uses the same construction. The train has been pinned up to the waist in the illustration but the pattern does not indicate any change in the construction.

The cut of women’s clothes, 1600-1930
Author: Norah Waugh; Taylor & Francis.
Publisher: Boca Raton, FL : Routledge, an imprint of Taylor and Francis, [2013]. ©1987.

https://www.worldcat.org/title/cut-of-womens-clothes-1600-1930/oclc/1074444804&referer=brief_results
My redrawing after a pattern in Cut of Women’s Clothes, 1600-190 by Norah Waugh

The cut of women’s clothes, 1600-1930
Author: Norah Waugh; Taylor & Francis.
Publisher: Boca Raton, FL : Routledge, an imprint of Taylor and Francis, [2013]. ©1987.


https://www.worldcat.org/title/cut-of-womens-clothes-1600-1930/oclc/1074444804&referer=brief_results

And again this mantua is shorter at the front than the anticipated petticoat hemline (see image of overlaid pattern drafts.)

These are unfortunately the only garments with patterns I have been able to find but there are several more that have been catalogued and the skirt layout captured in photographs.

The Metropolitan Museum has another early mantua example and the photographs do suggest the construction is of a kind- comparing the alignment of the pattern to the outside of the side back join in fabric shows it is in line with the hem not the seam.

Mantua
Date:ca. 1708
Culture:British
Medium:silk, metal
Credit Line:Purchase, Rogers Fund, Isabel Shults Fund and Irene Lewisohn
Bequest, 1991
Accession Number:1991.6.1a, b

https://www.metmuseum.org/art/collection/search/81809

A mantua in the Victoria & Albert Museum in London has been dated to 1733-1740 based on fabric (earlier date) and cut (later date). This gown has been photographed to show the construction of the skirt. This photo shows the brocade has been reversed from below hip level of the back panels and most of the side panels. This is so that only the face of the brocade is seen when worn and pinned in place.

Mantua
Place of origin:
Spitalfields (probably, woven) Great Britain (made)
Date: 1733-1734 (woven) 1735-1740 (made)
Artist/Maker: Unknown
Materials and Techniques: Brocaded silk, hand-sewn with spun silk and spun threads, lined with linen, brown paper lining for cuffs, brass, canvas and pleated silk
Credit Line: Given by Gladys Windsor Fry
Museum number: T.324&A-1985

http://collections.vam.ac.uk/item/O71872/mantua-unknown/

The Lincolnshire Mantua has been dated to 1735 based on the fabric and over all pattern pieces. This particular mantua has the train and most side panels reversed so that when pinned for display only the face of the brocade is seen.

The Lincoln Mantua

https://www.lincolnshirelife.co.uk/posts/view/the-mystery-of-the-mantua

Mantua from after these examples can be recognised by the folding of the train which follows the folding of the Lincoln mantua and the floral brocades mantua in the V&A as above.

One of the earliest is a blue silk mantua at the Victoria and Albert museum. From the 1720s it retains the extra length in the train despite being pinned up.

Place of origin: Spitalfields (textile, weaving) England (mantua, sewing)
Date: ca. 1720 (weaving) 1720-1730 (sewing)
Artist/Maker: Unknown
Materials and Techniques: Silk, silk thread, silver-gilt thread; hand-woven brocading, hand-sewn.
Museum number: T.88 to C-19788

http://collections.vam.ac.uk/item/O13810/mantua-unknown/

A brown broacaded silk mantua is also of this earlier type and is dated to 1732-1740.

Place of origin: Spitalfields (textile, weaving) Great Britain (ensemble, sewing)
Date: ca. 1732 (weaving) 1735-1740 (sewing) 1870 – 1910 (altered)
Artist/Maker: Unknown
Materials and Techniques: Silk, silk thread; hand-woven brocade, hand sewn
Museum number: T.9&A-1971

http://collections.vam.ac.uk/item/O71535/mantua-unknown/

Other garments described as mantua are harder to confirm from the photos.

The earliest is held at the Los Angeles County Museum of Art with a date of 1700. It is perhaps the most stunning example of its kind. A deep rich blue silk satin, the petticoat completely covered in metal embroidery, the sleeves and stomacher ditto, only the train seems to be more sparsely covered.

Woman’s Dress (Mantua) with Stomacher and Petticoat
Italy, circa 1700
Costumes; principal attire (entire body)
Silk satin with metallic-thread embroidery
Center back length (Dress): 67 in. (170.18 cm)
Length (Stomacher): 16 1/4 in. (41.28 cm) Center
back length (Petticoat): 41 3/4 in. (106.05 cm)
Costume Council Fund (M.88.39a-c)

https://collections.lacma.org/node/170609

A stunning embroidered mantua is held at the National Museum of Wales, dated to the 1720s though much of the train has been removed during the nineteenth century.

COLLECTION AREA mwl
ITEM NUMBER 23.189.1
ACQUISITION Donation
MEASUREMENTS height (mm):1400 width (mm):2000 (max) depth (mm):1500 (max)
TECHNIQUES metal thread embroidery hand sewn weaving
MATERIAL damask (silk) metal thread silver parchment flax (spun and twisted) silk (spun and twisted)
LOCATION In store
CATEGORIES Court

https://museum.wales/collections/online/object/e2ce99c3-462b-3da3-af0a-953e4f94008d/Dress/?field0=string&value0=Tredegar&field1=with_images&value1=on&field2=string&value2=Dress&index=6

A pale blue damask(?) mantua is held at the Manchester Art Gallery and appears to also be sewn so as to allow the face of the brocade to always be arranged outwards.

mantua dress
Acknowledgement: © Manchester
City Galleries
Created by:
Created: 1740-1742

http://manchesterartgallery.org/collections/search/collection/?id=1989.220

Another blue and silver mantua is held at the Kyoto Costume Institute and again has skirt panels reversed so as to always display the face of the brocade.

Dress (Mantua) 1740-50s – England
Material Blue silk taffeta brocade with botanical pattern, buttons to tack train; matching petticoat.
Dimension Length from the hips 183cm (Train)
Inventory Number(s) AC10788 2002-29AB

https://www.kci.or.jp/en/archives/digital_archives/1700s_1750s/KCI_007

While this garment has been dated to the 1750s i believe it is somewhat earlier. The skirt as displayed does not fit well suggesting it was not worn over wide hoops. The train has been folded and appears to show the fabric has been reversed in a similar manner to the above folded mantua trains. So it could be 1720-1740.

A COURT MANTUA OF CHINESE IMPERIAL YELLOW SILK DAMASK, THE SILK CIRCA 1740, THE MANTUA 1750S
the bodice with long sweeping train of elaborately folded damask buttoning in swags onto two silk covered buttons at the small of the back, the bodice re pleated as a closed robe, the petticoats re-strung, shown here worn with a stomacher which is part of lot 141

https://www.christies.com/lotfinder/Lot/a-court-mantua-of-chinese-imperial-yellow-5018370-details.aspx

More working women of Koeln

It is frustratingly difficult to search for books printed in Koeln of the first half of the sixteenth century and it should not be. This was a hub of printing and publishing. But still.

Des Kunckels odder Spinnrockens Evangelia vom Montag an, biß auff Sambstag, mitsampt den Glosen, zu ehren den Frawen beschrieben
Johann von Aich, 1557
https://books.google.co.nz/books?id=SAtPAAAAcAAJ

There is so much going on here! And it’ll take a while to unpack everything except that this pretty much confirms a few ideas I had based on the sheer number of headgear items from the inventories.

Of note are the two wulst like headdresses (one in each plate). Please do note they are not simply rear view of the headdress iconic to this region, there are no wings. Weiditz gives us that view at it has a button on it.

Also two examples of a twisted unshaped headdress (second plate here) that looks for all the world like the type of headdress in the Lemberg finds.

There are also simple braids. So with the iconic headdress and these we are on track to this being a fairly representative example of dress the artist(s) knew.

But look at those kleyr! The circular cape like outer garments with little clasps are very 1520s but then look! Gathered kleyr (aka goller aka partlet)! With no centre front opening! And they are simply tied under the arms- or have a short narrow strip that is otherwise fastened front to back. But this is different to most woodcuts outside this region that show a section that fits under the arms. And there are portraits with this type of closed necked kleyr.

Also the mix of guarding- either deep or not at all. And all the rear fullness of the skirts. So good. I mean I knew, but it’s nice to have it on every single image that shows the side and back of dress.

And of course how can we ignore the pin on outer sleeve. Or it looks like a button. Pinned is more frequently depicted but given how few depictions we have of the sleeve on the outside I’m still hedging bets.

So I’ll continue to look for printed works from Koeln- note using the era appropriate “Collen” still doesn’t help look for books as I can’t get the boolean AND to work in Archive.org and there is a bit of fuzziness in google books when organising by date and I have mostly exhausted various universities.

But this is a wonderful addition.
